STRIP™
Structural Investigation Processor
Overview
Structural Investigation Processor (STRIP™) is a software application designed to enable engineers to investigate structural modeling and behavior under external forces, and visualize induced internal forces. Designed for Windows® operating systems. Supports a neutral format to share model and analysis result data with third party structural applications.
Model Verification
- Structural element activation for display by element attributes
- Element identification by multi-color display
- Element/Node numbering and information display
- Hidden line removal, shrunken element display
- Graphical restraint and force display
- Multiple window display
Response Visualization
- Deflected shape of the structure
- Deflection and Stress contour diagrams
- Structure Animation
- Bending Moment and Shear Force diagrams
- Force fringes of Truss and Beam elements
Reporting & Export
- Summary output of selective results
- Detailed results output for different load cases and combinations
- Results in DXF format for graphical presentation
- Hard copy prints of graphical display
- Neutral data format to support third party applications
Part of the General Structure Package (GSP)
