SLAM™
Structural Layout Modeler
Overview
Structural Layout Modeler (SLAM™) is an application to model building structures in 3D with simple modeling concepts defined in 2D with 3D visualization capabilities. Takes advantage of general building designed in levels and plan laid out using grid lines. Also models lintels, chajjas, and provides comprehensive load generation including seismic and wind loads. Supports DXF import to combine space frames with building models.
Structural Modeling
- Simple modeling concept extending building levels and grids
- Create and manage structural properties with import/export across projects
- Automatic structural layout generation and selective copy across levels
- Create column, beam, slab, lintel and chajja elements
- Create and manage walls on beams and standard stair case types
- Auto load transfer from slabs, walls, lintels, chajjas and stairs
- Auto seismic and wind load generation
- Import DXF geometric models and convert to structural model
- Create multiple load cases and load combinations
Model Visualization
- Structural element activation for display by element attributes
- Element identification by multi-color display
- Element/Node numbering and information display
- Hidden line removal, shrunken element display
- Graphical restraint and force display
- Multiple window display
- Hard copy prints of graphical display
Part of the Building Layout Package (BLP)
