DXFMOD™
DXF Structural Modeler
Overview
DXF Structural Modeler (DXFMOD™) is a standalone application to convert 2D and 3D structures modeled in AutoCAD environment. The aim is to provide a graphical interface to model general structures, take away the laborious process of creating the model manually, generate numeric data automatically and for model verification. It can also be used as an independent structural modeler to model any structure either in 2D or 3D from scratch.
Structural Modeling
- Conversion of DXF geometric models to structural model
- Create new nodes and offset and array copy of nodes
- Create new truss, beam and plate/shell elements and offset/array copy
- Modify element properties, match property and convert between element types
- Create nodal restraints and beam element end force releases
- Create multiple load cases, nodal, beam and plate/shell pressure loads
- Create analysis file for 3D finite element analysis
- Save data in neutral file format for interoperability
Model Visualization & Verification
- Structural element activation for display by element attributes
- Element identification by multi-color display
- Element/Node numbering and information display
- Hidden line removal, shrunken element display
- Graphical restraint and force display
- Multiple window display
- Hard copy prints of graphical display
Part of the General Structure Package (GSP)
